Nylatron® NSM is a proprietary cast nylon 6 formulation containing solid lubricant additives which grant this materials self-lubricity, excellent frictional behaviour, superior wear resistance and outstanding pressure-velocity capabilities [up to 5 times higher than conventional cast nylons]. Being particularly suited for higher velocity, unlubricated moving parts applications it is the perfect complement to the oil-filled grade Ertalon® LFX.
MAIN CHARACTERISTICS
- Excellent slip properties
- Low coefficient of friction
- Self-lubricating
- High wear resistance
- Pressure-speed values up to 5 times higher than conventional polyamides
- Good resistance to high energy radiations (Gamma and X Rays)
- Good electrical insulation properties
- High mechanical damping capacity
- Easy machining
ApPlicaTIONS
- Bushes with rotation, subject to high loads
- Sliding guides
- Large parts
- Especially recommended for non-lubricated applications with high creep speeds
- Bearings
- Rollers, wheels, wear components
- Wear pads
- Gears
